DAF-867-190XXX Single Needle Compound Feed Sewing Machine
The DAPSEW DAF-867-190XXX is a single needle flat bed compound feed lockstitch sewing machine designed for automotive upholstery, furniture, leather goods, bags and other medium- to heavy-duty applications. Featuring bottom feed, needle feed and alternating walking foot movement, the machine provides controlled feeding of multilayer materials. The series offers 26 mm XL and 32 mm XXL hook options, with Basic, Automatic and Advanced Automatic configurations to meet different sewing requirements.
DAF-867-190XXX Single Needle Compound Feed Sewing Machine
Product Overview
The DAPSEW DAF-867-190XXX Series is a single needle flat bed compound feed lockstitch sewing machine designed for sewing medium- to heavy-duty materials in automotive upholstery, furniture manufacturing, leather goods, bags and industrial textile applications.
The machine features a triple feed system combining bottom feed, needle feed and alternating walking foot movement to help maintain consistent material feeding when sewing multiple layers.
The series includes six models with 26 mm XL or 32 mm XXL hook options and three configuration levels: Basic, Automatic and Advanced Automatic.
Key Features
Triple Feed System: Bottom feed, needle feed and alternating walking foot movement for controlled multilayer sewing.
Single Needle Lockstitch: Suitable for assembly seams, reinforcement stitching and decorative topstitching.
XL / XXL Hook Options: Available with 26 mm or 32 mm hook configurations.
Extended Working Space: Provides room for handling upholstery panels and leather components.
Adjustable Alternating Presser Feet: Accommodates different material thicknesses.
Automatic Sewing Functions: Selected models offer automatic thread trimming, backtacking and presser foot lifting.
Advanced Configuration: Available with second stitch length, second thread tension and quick foot stroke adjustment.
Technical Specifications
Common Specifications
| Specification | DAF-867-190XXX Series |
|---|---|
| Machine Type | Single Needle Flat Bed Lockstitch |
| Stitch Type | 301 Lockstitch |
| Feeding System | Bottom Feed + Needle Feed + Alternating Walking Foot |
| Needle System | 134-35 |
| Needle Size | Nm 90–180 |
| Maximum Stitch Length | Up to 12 mm |
| Maximum Sewing Speed | Up to 3,000 spm |
| Maximum Alternating Foot Stroke | 9 mm |
| Presser Foot Lift | 10 mm Manual / Up to 20 mm with Lifting Mechanism |
| Working Space | 335 × 125 mm |
Model Comparison
| Specification | 190020 | 190040 | 190122 | 190142 | 190322 | 190342 |
|---|---|---|---|---|---|---|
| Configuration | Basic | Basic | Automatic | Automatic | Advanced | Advanced |
| Hook Diameter | 26 mm | 32 mm | 26 mm | 32 mm | 26 mm | 32 mm |
| Automatic Thread Trimming | - | - | ✓ | ✓ | ✓ | ✓ |
| Automatic Backtacking | - | - | ✓ | ✓ | ✓ | ✓ |
| Automatic Foot Lifting | - | - | ✓ | ✓ | ✓ | ✓ |
| Second Stitch Length | - | - | - | - | ✓ | ✓ |
| Second Thread Tension | - | - | - | - | ✓ | ✓ |
| Quick Foot Stroke Adjustment | - | - | - | - | ✓ | ✓ |
✓ Included · - Not included
Full model numbers use the prefix DAF-867-, for example DAF-867-190142.
Typical Applications
Automotive Upholstery
Sewing car seat covers, interior panels, headrests and other upholstery components.
Furniture Upholstery
Assembly and decorative stitching on sofa covers, cushions and furniture panels.
Leather Goods
Sewing leather bags, accessories and suitable multilayer leather products.
Bags and Luggage
Assembly stitching and reinforcement sewing on bag panels and luggage components.
Industrial Textiles
Sewing suitable canvas, coated fabrics and other medium- to heavy-duty textile materials.
Machine Details and Options
Basic Models – 190020 / 190040
Standard sewing configurations with manual reverse sewing and presser foot lifting.
Automatic Models – 190122 / 190142
Equipped with automatic thread trimming, backtacking and presser foot lifting.
Advanced Automatic Models – 190322 / 190342
Include automatic functions together with second stitch length, second thread tension and quick alternating foot stroke adjustment.
Hook Options
26 mm XL Hook
32 mm XXL Hook
Frequently Asked Questions
What materials can the DAF-867-190XXX sew?
The machine is designed for automotive upholstery, furniture fabrics, leather goods, bags and suitable medium- to heavy-duty materials.
What is the difference between the 26 mm and 32 mm hooks?
The 32 mm XXL hook offers a larger hook configuration than the 26 mm XL version. Selection depends on sewing requirements and the preferred bobbin capacity.
What is the difference between Basic and Automatic models?
Automatic models include thread trimming, backtacking and presser foot lifting, while Basic models use manual operation.
What additional functions are available on Advanced models?
Advanced configurations include second stitch length, second thread tension and quick alternating foot stroke adjustment.
Is a double needle version available?
Yes. The DAPSEW DAF-867-290XXX Series is available for parallel-row stitching.
Request a Quotation
Looking for a single needle compound feed sewing machine for upholstery, leather goods or industrial textiles?
Contact DAPSEW with your sewing materials, thread requirements, preferred hook size, required automatic functions, quantity and destination country.
Our team can help you compare the available DAF-867-190XXX configurations and select a suitable machine for your application.
