Safety Stitch Machine

Safety stitch machine a Masterpiece of Pegasus' Technology

Top of the line machines to produce beautiful stitches,with reliable mechanism, technology that achieves high speed and durability, plus ease of operation and maintenance Offers full line of subclasses that provide high quality finishes in various operations.A wide variety of labor saving devices help increase productivity.

Plain seaming extra light to light weight fabrics, Plain seaming light weight fabrics, such as dress shirts, with puckering preventive capability.

Produces beautiful stitches

You will easily obtain well-balanced and beautiful stitches with easy-to-adjust thread tensions. The machines feed the fabric more properly to achieve high quality stitches.The double chain stitch, safety stitch machines produce neatly finished seams with balloon stitches formed by looper threads of good texture.

High productivity with

High speed machines

Increases productivity at a max speed of 8,500 rpm.

Increased durability

Includes the mechanism that reduces wear and tear of parts increasing durability.

Ease of operation

Replacing the needles, threading the machine and adjusting thread tension are easy.

Easy to maintain the machine

Alignment marks on looper thread guides and double chain stitch looper thread take-up eliminate the need for bothersome measurement using a ruler.Thanks to the micro adjustment feature, a precise adjustment is easily made on the lower looper front-to-back movement and double chain stitch looper front-to-back movement.

Easy to adjust the stitch length All you have to do is press the push button.

Tilt adjustment on the feed dog is readily made.

Easy access to the adjustment screw with out opening the cover

Adjusting the differential feed ratio is easy

A fine adjustment is effortlessly made.

All subclasses equipped with upper and lower needle/thread cooler devices(HR) that protect the fabrics and threads against heat.

Heat is generated on the needle due to friction when the needle penetrates the fabric at high speeds. This causes thread breakage and/or stitch skipping.This series is equipped with HR device that always prevents heat generation on the point of the needle, allowing the thread to move smoothly and producing the stitches uniformly.

Thread chain cutter (KS/KH)Devices that suck up the thread chain by air and cut it, No scissors are needed.There are two types of suction inlets, vertical type ( KS: the suction inlet is positioned vertically to the cloth plate) and flat type (KH: the suction inlet is positioned flush with the cloth plate).

Tape and/or thread chain cutter (TK/AT)Devices that trim the tape and thread chain when sewing is completed Manual type:TK Two types of switches available, finger switch and knee switch to get TK actuated The device operates on either pneumatic or electric power sources.

AT The sensor detects the fabric edge to trim the tape.
This AT includes the controller that regulates the length to be trimmed by stitch counting.

Electronic hemming guide (EH)Eliminates the need for inspection for run-offs when sewing is completed.When the sensor detects the over-lock seams on the pre-closed sides of garments, this guide automatically operates to make the machine run to ward the inside of the fabric, preventing run-offs.

Presser foot lift (PL)Reduces operator fatigue. Pressing the treadle actuate the air cylinder to raise the presser foot.

Backlatching device (BT)Device that backlatches the thread chain by sewing it back into the seams on the fabric at the start of sewing. Eliminates the need for a bartacker and the operator, reducing production time and dramatically increasing efficiency.

Belt feeding device (BF)The belt on this device forcibly feeds the fabric under the presser foot.preventing the fabric from plyshifting. Suitable for the fabrics and operations that tend to plyshift, such as attaching collars.

Fabric misalignment alarm (SD)Alerts you with light and sound when fabric misalignment occurs during sewing, such as attaching sleeves or closing sides. The sensor detects fabric misalignment.Eliminates the need for sewing the fabric over againdue to plyshift.

EX Specifications in common:
